Home Building Materials US Steel Conduit and Fittings EMT Conduit & Fittings EMT conduit pipe
IMC Conduit Specifications:
Surface Treatment: Pre-galvanised
BS4568:1970/BS EN61386/IEC60423:1993
| Size |
Outside Diameter (min/max) |
Wall Thickness (mm) |
Length (m) |
| 1/2'' | 20.7 | 1.79 | 3.05 |
|
3/4'' |
26.26 |
1.90 | 3.05 |
| 1'' | 32.77 | 2.15 | 3.05 |
| 1-1/4'' | 41.59 | 2.16 | 3.05 |
| 1-1/2'' | 47.82 | 2.29 | 3.05 |
| 2'' | 59.93 | 2.41 | 3.05 |
| 2-1/2'' | 73.10 | 3.75 | 3.05 |
| 3'' | 88.90 | 3.75 | 3.05 |
| 3-1/2'' | 100.86 | 3.75 | 3.05 |
| 4'' | 113.44 | 3.75 |
3.05 |
